Minimalist form. Maximum acoustic impact.

Track Wall Panels by Impact Acoustic are designed to elevate both the function and form of vertical surfaces. With their refined lines, seamless installation, and sustainable composition, they deliver high-end acoustic performance while enhancing visual harmony.

Crafted from ARCHISONIC® Felt or Riftcut, made with 60% post-consumer recycled PET, these panels are lightweight, durable, and environmentally responsible. Each panel measures 1200 × 2800 mm and integrates effortlessly using Z-clip aluminum profiles, allowing for clean, concealed mounting.

You can choose between two edge treatments: the standard raw edge or the Flip-Edge, which folds over to hide the core for a more polished finish. Perfect for creating continuous wall compositions with a refined look.

Available in 36 solid colors and 24 Riftcut wood-like finishes, Track Wall Panels give you total aesthetic control. Ideal for offices, hospitality, education, and public spaces, these panels improve acoustic comfort while contributing to a serene, focused environment.

‍

Request a quote
Variant
Variant
Option oneOption twoOption three
Add to cart
Buy now
Free shipping over $50
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.
Product specifications
Technical information
Tags
Dimensions

• Width: 1200mm (47”)

• Height: 2800mm (110”)

• Thickness: 40mm (1 1/2”)

Composition

• Panel: 100% PET (60% post-consumer content)

• Substructure profiles: Anodized black aluminum

Thickness
Finishing material
PET Felt
Weight
• Panel: 24kg (±10%) / 53 lbs (±10%) (without substructure) • Substructure profiles: 0.5kg (±10%) / 1.1 lbs (±10%) (for four profiles)
Colours available
• Archisonic® Felt: 36 colors across 8 distinct families • Archisonic® Riftcut: 24 printed finishes inspired by natural dyes
Sound absorption

• ISO Testing:

- αw: 0.65

• ASTM Testing:

- NRC: 0.60

• Standards:

- ISO 354: Measurement of sound absorption

- ISO 11654: Sound absorber classification

- ASTM C423-17: Sound absorption test

- ASTM E84: Fire safety test

Maintenance

• Daily ceaning: Alcohol solution (75%) (e.g., Pantasept)

• Dust removal: Feather duster or vacuum cleaner

• Heavy dirt: Hydrogen peroxide treatment

Recyclability
Minimum 60% post-consumer recycled PET
Fire resistance class EU
DIN EN 13501-1: B-s1, d0 | ASTM E84 Class A
Green labels

• VOC Emission:

- 28 Days French Regulation: A+.

- BREEAM® (International, UK, NL, SE, NOR): Exemplary.

- CDPH Standard V1.2: Pass.

• Certifications:

- Declare label, Cradle to Cradle, UL Environmental Product Declaration.

- Member of US Green Building Council, Ecobau 1st Priority, Climate-KIC.

- VOC emissions compliant with LEED EQ credit (low-emitting products).

- SCS Recycled Content.

• Ink Certifications (for printed Riftcut finish):

- UL Greenguard, No NVC, No VOCs, Vegan, CP65 & RoHS3 compliant.
